Revised the paper with UI diagrams, class diagrams, sequence diagrams and topology diagrams and paragraphs based on the diagrams

Notes on the Project

need to deliver the next project iteration in a week. It will include:

1. UI diagrams (leftover and reprinted from February's project)
2. class diagrams
3. sequence diagrams
4. topology diagrams

the link to our latest lecture:

https://www.loom.com/share/1978e310e454459288647bb72af639e6

https://www.loom.com/share/7676b8cd9d264ef1b7ef79e7f47ee6d9

This lecture is about software deployment and server topology, where servers might reside outside your immediate control. It talks about using cloud craft diagramming services, which your team must build this month.

• https://cloudcraft.co/

Two sample diagrams were created during the lecture, both are linked here: https://github.com/stefanbund/SDLC-GITHUB/blob/master/classArchetype.png
