Facility Planning—Floor Plan, Part 1

This assignment consist of creating a floor plan including the following

• Facility structure
  • Walls
  • Doors
  • Hallways
  • Waiting areas
  • Other related structural components
  • Facility areas
    • Customer service and amenities
      • Reception desk, bathroom, shower, vending machine, etc.
• Patient consultation areas
• Clinical support areas
  • Nurses station, charting areas, etc.
• Administrative offices
• Building support
  • Laundry, generator facilities, housekeeping, etc.
• Diagnostic and treatment space equipment and location
• Mechanical equipment
  • Space for laboratory equipment, radiology equipment, gases like oxygen, and suctions
